VGA to DVI Converter

The VC160 connects VGA based video devices to DVI digital devices such as monitors, projectors,etc. Small yet powerful enough, the VC160 is easy to install and offers high video resolutions (up to 1600 x 1200). In addition, the VC160 offers convenient storage and selection of user-defined picture adjustment presets with the help of push buttons.

Features:

	1 VGA input, 1 DVI-D output
	Connects VGA based video devices to DVI digital monitors or DVI equipped projectors
	High video resolution up to 1600 x 1200@60Hz
	Memory set button-allows storing and selecting user settings
	Easy installation

Diagram :

Package Content:

	1x VGA to DVI Converter
	1x VGA Cable (6 feet / 1.8 meters)
	1x User Guide
	1x Power Adapter

Specification :

LEDs
Power On	1 (Green)
Power Consumption	DC 5.3V, 3W
Video Resolution	1600 x 1200 @ 60Hz; DDC2B
Resolution	1600 x 1200 @ 60 Hz, DDC2B
Connectors
Video Input	1 x VGA D-Sub Male
Power	1 x DC Jack
Video Output	1 x DVI-D Female
Switches
Direction Adjustment	4 x Semi-recessed Push-buttons
Memory	1 x Semi-recessed Push-button
Environment
Operation Temperature	32F ~ 122F (0 ~ 50 C)
Storage Temperature	-4F ~ 140F (-20C ~ 60C)
Humidity	0 ~ 80% RH, Non-condensing

Physical Properties
Housing	Metal
Case Weight	25.3 lb.
Unit Weight	0.46 lb. (0.21 kg)
Unit Weight with package	1.6 lb. (0.72 kg)
Case Dimension	13x 19.5x 13 in. (33.0x 50.0x 33.0 cm)
Case Qty	15
Unit Dimension	1.0x 4.0x 3.1 in. (2.5x 10.0x 7.9 cm)
Unit Package Dimensions	9.5x 2.5x 6.5 in. (24.2x 6.4x 16.5 cm)
